Soil Testing Small 100 Meters Engineering Geological Drilling Rig
XY-1 Engineering Geological Drilling Rig Description
XY-1 Core drilling rig is suited for the applications of general exploration and investigation, geophysical prospecting. Road and construction survey, blast holes and other drilling operations.
XY-1 Engineering Geological Drilling Rig Specification
| Drill |
| Drilling depth | 100m |
| Drill rod diameter | 42mm |
| Initial hole diameter | 110mm |
| Final hole diameter | 75mm |
| Angle range | 75-90 |
| Dimensions (L*W*H) | 1640*1030*1440(mm) |
| Dimensions (L*W*H) | 1640*1030*1440(mm) |
| Weight without power unit | 500kg |
| Stroke XY-1 | 350mm |
XY-1 Engineering Geological Drilling Rig Characteristic
(1) It has a hydraulic automatic feeding structure to improve the drilling efficiency and reduce the labor intensity of workers.
(2) The ball clamp clamping mechanism is used to replace the chuck, which can reverse the rod without stopping the machine, which is convenient, safe and reliable.
(3) It is equipped with a hole bottom pressure gauge to indicate the pressure, which is convenient to master the situation in the hole.
(4) The handle is centralized and easy to operate.
Drilling Rig Exploration Method
This is a survey method to find out the underground geological conditions. It can be divided into: (1) geophysical exploration: lithology, groundwater level, karst cave distribution, etc. are divided according to the conductivity, magnetism, density and the propagation speed of elastic wave in different underground strata and media (water, cavity, rock, etc.). Guide drilling. (2) Drilling: combined with pit (groove) exploration. 3) penetration: it is both an exploration method and an in-situ test method.
Soil Sampling Procedure
Divide the field into different homogeneous units based on the visual observation and farmer’s experience.
Remove the surface litter at the sampling spot.
Drive the auger to a plough depth of 15 cm and draw the soil sample.
Collect at least 10 to 15 samples from each sampling unit and place in a bucket or tray.
If auger is not available, make a ‘V’ shaped cut to a depth of 15 cm in the sampling spot using spade.
Remove thick slices of soil from top to bottom of exposed face of the ‘V’ shaped cut and place in a clean container.
