ST 350 Meters Depth Drilling Machine 92kw Diesel Engine Crawler Chassis Mounted Drilling Rig
ST 350 Pneumatic Borewell Machine Descrption
ST 350 Pneumatic Drilling Rig Machine is is equipped with powerful hydraulic rock drills that offer high penetration rates, reliability, and excellent fuel economy.
ST 350 Pneumatic Borewell Machine Technical Information
| Drilling Rig Model | ST 350 Pneumatic Drilling Rig Machine |
| Drilling depth | 350m |
| Dia.hole | φ140 - 325mm |
| Advance Length one time | 6.6m |
| Working pressure | 1.7-3.3MPa |
| Air consumption | 17-35m³/min |
| Length of rod | 1.5m,2m,3m, 6m |
| Dia. Of rod | φ89,φ102,φ114 |
| Lifting power | 24T |
| Rotation torque | 6200-85000N.m |
| Rotation Speed | 55-115r/min |
| Diesel Engine | Yuchai |
| Engine Power | 92Kw/2200rpm |
| Travelling speed | 0-2.5 Km/h |
| Climb capacity | 30° |
| Weight | 9000kgs |
| Dimension | 5900x2000x2850mm |
| Application | Complicated geological conditions: Rock, Mud, Sand etc. |
ST 350 Pneumatic Borewell Machine Applications
it is mainly applicable to industrial and civil drilling, geothermal drilling, has the advantages of compact structure, fast advancing, mobile and flexible wide application region etc., It is especially suitable for water intake in mountainous and rocky strata..
ST 350 Pneumatic Borewell Machine FAQ
Q 1: What kind of drilling rig do you have?
A: We mainly produce small hydraulic drilling rig, water well drilling rig, core drilling rig, engineering drilling rig, geological exploration drilling rig, etc., and we will recommend the suitable model according to your exact requirement .
Q 2: Where is the address of your company?
A: Our factory is in Jinzhou, Shijiazhuang City, Hebei Province, China
Q 3: Are you a manufacturer or a trading company?
A:We are a 20 years professional manufacturer with ISO certificate. We have a large modern drilling rig plant in Hebei, China.
Q 4: How long is your delivery time?
A: Small hydraulic drilling rigs generally take 5-7 days, and large pneumatic water well drilling rigs generally take 7-15 days. If there is an urgent order, please contact our sales in advance.
Q 5: How long is the warranty of your well drilling rig?
A: Except for consumable spare parts, the whole machine shall be one year.
Q6: How long can your air compressor be used?
A: Normally more than 10 years.
