Water Well Rotary Drilling 180m Pneumatic Borewell Machine

Brand Name : ST

Model Number : ST-180

Certification : ISO 9001

Place of Origin : hebei china

MOQ : 1 set

Payment Terms : Western Union, TT

Supply Ability : 2000sets/month

Delivery Time : 5days

Packaging Details : Customized

Usage : Pneumatic Borewell Machine

Weight : 4.5T

Drilling depth : 180 meters

Dimension(L*W*H) : 3800*1500*2200mm

Drilling hole diameter : 140-254mm

One-time advance length : 3m

Walking speed : 2.5km/h

Climbing angles (Max.) : 30

Equipped capacitor : 55KW

Drill pipe diameter : 76/89mm

Application : Water well drilling rig

Colors : red ,yelllow

Contact Now

Borehole Drilling Rig Water Well Rotary Drilling Rig 180 Pneumatic Borewell Machine

180m Pneumatic Borewell Machine

ST180multi-function geothermal water well drilling rig machine is a lightweight, high efficiency, multifunctional drilling rig.

ST180 water well has the characteristics of advanced structure, easy to use, high efficiency, reliable, durable etc.It is widely used in drilling water wells, agricultural irrigation well and Geothermal air conditioning hole and other usages of geothermal well hole.

ST180 portable water well drilling rig machine with high efficiency is particularly applicable to mountain area and rock formation water engineering.

Pneumatic Borewell Machine Main Parameters

Model	ST180
Drilling hole diameter	140-254mm
Drilling depth	180m
One-time advance length	3.3m
Walking speed	2.5km/h
Climbing angles (Max.)	30
Equipped capacitor	55kw
Using air pressure	1.7-2.5mpa
Air consumption	17-31m³/min
Drill pipe length	1.5m, 2.0m, 3.0m
Drill pipe diameter	76mm, 89mm
Rig lifting force	12t
Swing speed	45-65rpm
Swing torque	3200-4600(N.m)
Dimension	380015002200mm
Weight	4500kg

FAQ

Q1: Are you a manufacturer?

A: Yes, we are a professional down the hole drill rig and top hammer drill rig manufacturer.

Q2: What does your company produce?

A: The main products of our company include blasting drilling rig,water well drilling rig and all kinds of air compressors.

Q3: How about your delivery time?

A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, it depends on different products.

Q4: What methods of payment do you accept?

A: We accept T/T.

Q5: Do you offer any deals or discounts?

A: Yes, price depends on different quantity, different quantity will give you different price.
