Multipurpose Water Well Drilling Rigs Water Borewell Machine Price In India
pneumatic crawler water well drilling rig Brief Introduction
1. Drilling depth can reach 300m
2. Steels quality is good, torque is large
3. Easy operation, free-maintaining
4. For various complex stratum, such as pebble bed, aggregate bed.
5. Saving money, compact construction, easy moving
6. Applicable to industry, residents drilling, ground drilling, large diameter, deep drilling, footage fast, flexible and efficient.
water well drilling rig main parameter:
| Drilling diameter(mm) | Ø90- Ø273 |
| Drilling depth( m) | 150-300 |
| Drill rod diameter(mm) | Ø76,Ø89, Ø102 |
| Drill inclination(°) | 90 |
| Rotator output speed(r/min) | 14-500 |
| Rotator output torque(N.m) | 13428-250 |
| Rotator feeding stroke (mm) | 3400 |
| Gyrator pressure (k.N) | 35 |
| Revolver lift(k.N) | 80 |
| Revolver to increase speed(m/min) | 0-12 |
| Walking way / Climbing angle | Crawler walk /15° |
| Input power(Diesel engine)(kW) | 48 |
| Rated speed(r/min) | 2400 |
| Oil pump flow(L/min)/压力Pressure(MPa) | main pump 60/20,Auxiliary pump 60/20 |
| Dimension(L*W*H)mm | 5400X2120X2650 |
| weight(kg) | 7200 |
FAQ
1, Are you trading company or manufacturer?
We are professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, DTH drilling rig, piling rig, etc. Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.
2, Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provid the training for your staff.
3, What about the qaulity warranty?
We offer one-year quality warranty for machines' main body.
4, How long can you deliver the machine?
Generally, we can deliver the machine in 7 days.
