Air Compressor ST-300 Pneumatic Well Drilling Rig

Brand Name : ST

Model Number : ST-300

Place of Origin : hebei

MOQ : 1set

Payment Terms : T/T, L/C, Western Union

Supply Ability : 2000sets/month

Delivery Time : 5-7days

Packaging Details : no packing

Certification : iso

Weight of whole machine : 7T

Drilling caliber : 140-325mm

Drilling depth : 300m

One-time push length : 3.4m

Contact Now

300m Air Compressor Pneumatic Bore Well Drilling Machine ST-300

Pneumatic Water Well Drilling Rig Brief Introduction

FL series bore well drilling machine is a type of light, high efficient and multifunctional drilling rig. It is widely applied in water well, irrigation well or other boreholes, especially good for mountain areas or rock foundations. The drilling rig adopts new hydraulic technology, supporting high-torque hydraulic motor rotation and large-bore hydraulic cylinder propulsion.

The Main Parameters

Weight of whole machine	7T
Drilling caliber	140-325mm
Drilling depth	300m
One-time push length	3.4m
Walking speed	2.5km/h
Climbing ability	Max. 30
Power of main machine	75.8kw
Working pressure	1.7-3.0mpa
Air consumption	17-35m3/min
Diameter of drill rod	76, 89, 102mm
Length of drill rod	1.5, 2.0, 3.0m
Lifting force	18T
Rotation speed	40-70rpm
Rotation torque	5700-7500N.m
Dimension	410019502600mm

Air Compressor ST-300 Pneumatic Well Drilling Rig
