Name: Farm GX390 13HP 1Ton Micro Tracked Dumper
Brand: ShiTan
Price: 1 USD

Model Number : SF0620H

Certification : ISO9001

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Delivery Time : Within 7-12 days

Payment Terms : L/C, D/A, T/T, Western Union

Brand Name : ShiTan

name : track dump carrier / mini crawler dumper

Drive Wheel : Crawler drive

Transmission Type : Automatic

Fuel Type : Petrol / Gasoline

Hydraulic Pump : Piston Pump

Cab : Enclosed

Application : Farm, Mining, Transport

Capacity (Load) : 1 - 10t

Contact Now

Power Barrow Rubber Micro Tracked Dumper , 1 Ton Farm Tracked Dumper

Detailed Description of tracked power barrow / Mini Dumper

Features of new tracked power barrow /Mini Dumper

Tracked power barrow/Mini Dumper Technical Data

Engine :	Mitsubishi 13HP or HONDA GX390 13HP or CHINA Diesel Engine
Dry Weight:	480kg
Transmission system Hydraulic system
Type:	Hydrostatic Hydraulic Pump: Piston Pump
Hydraulic Pump:	2xvariable displ. Flow Std: 1x13.5l/min(1x3.6gpm)
Flow:	2x32.4l/min(2x8.5gpm)
Hi-flow:	1x22l/min(1x5.8gpm)
Hydraulic Motors:	2x orbital Max
Pressure:	150bar(2180psi)
Brake Parking:	Mechanical Main
Valve:	2-3way
Cooler system oil:	air
Skip Tipping System:	Hydraulic
Loading Capacity:	1000kg
Standard Track Width:	180mm(7.1in)
Track roller:	3
Rockling rollers and track tensioning:	Yes
Max Travel Speed:	0-3.9mph
Dimension:	2640mm x 800mm x 1140mm
SELF LOADING SHOVEL:	NO
HI-TIP:	NO

Farm GX390 13HP 1Ton Micro Tracked Dumper
