Rubber Track Mini Track Transporter / Mountain Vehicles Crawler Transporter
Specifications
Body weight: 1.4 tons
Weight: 2 tons
Lorry-mounted crane hoisting biggest: 1 ton
Boom lifting height: 3 m
Gear and speed: speed + 3 fastest forward + 1 reverse 8 km The slowest 0.6 kilometers
Car size: 1.6 m * 2.0 m (customizable)
Climbing ability: 28 degrees
Engine power: 28 horsepower
Obstacle ability: 30 cm
The vehicle length * width * height (cm) : 340 cm * 160 cm * 120 cm
Chassis length * width * height (cm) : 195 cm * 160 cm * 45 cm
Diesel engine models: WL - 28
Diesel power (kw/r/min) : 20.24 kw / 2200 r/min
Car low height (cm) from the ground: 25 cm
Packing case length * width * height (cm) : 180 cm * 160 cm * 40 cm (customizable)
The Pacific Ocean road load (kg) : 2000 kg
Maximum gradient load (kg) : 1200 kg
Speed: the slowest: 1.2 km/h: fastest 6 km/h
Obstacle ability: 20 degrees slope, the largest vertical height of 20 cm obstacles
Wading depth: 40 cm
Wade mud depth: 20 cm
Caterpillar grounding length (cm) : 130 cm
Crawler type: 400 mm
Product features
1. compact, maneuverable, flexible, easy to operate, wide gear shift and large capacity.
2. The working ground of crawler is smaller than the pressure, and not hurt he lawn. It has good performance and strong ability to climb the slope.
3. It is widely used in the transportation of farmland, orchard, greenhouse, nursery beds, beaches, snow fields, construction sites and other complete topography and narrow roadbed.
