Name: Portable Hydraulic Core Drilling Machine Water Well Drilling Equipment
Brand: ShiTan
Price: 4800 USD

Brand Name : ShiTan

Model Number : ST200

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD4800-6200

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 2000sets /year

Delivery Time : 10 days after payment

Packaging Details : Plastic film and Standard export wooden box

Name : water Well Drilling Rig

guarantee time : 1 year

loading port : Tianjin

weight : 600kg

OEM : OK

Drilling depth : 200M

Contact Now

Qualtiy Red Mounted Boring Borehole Water Well Drilling Rig Sell to South Africa

Competitive Advantage:

1. 12 years factory
2. ISO Certificate
3. Had export to Many countries
4. Professinal technical team
5. 180-720 days guarantee time

Portable Hydraulic Core Drilling Machine , Water Well Drilling Equipment

Technical Specification

ST-200 Type
Drill		Swivel Head
Drilling depth	Max.200m	Spindle speed	(4-speed) 115 230 505 1010r/m
Hole diameter	Max.300m	Spindle stroke	450kmm
Drill rod diameter	42mm	Spindle pull-down	Max.15KN
Angle range	90-75	Spindle lifting capacity	Max. 25KN
Oil pump		Water pump
Model	YBC-20/125	Model	Horizontal reciprocating single-acting piston pump
Rated pressure	12.5Mpa	Working pressure	Max. 1.2Mpa
Flow speed	20ml/r
Rated speed	2000r/min
Hoist		Power(diesel)
Max. lifting capacity	20KN	Model(diesel engine	ZS1115
Hoisting drum revolution	20.39.85.170r/m	Rated power	16.2KW
Drum diameter	140mm	Rated speed	2200r/m
WEIGHT	AROUND 600KG
SIZE	17308601360mm
